Genie telescopic S-booms have a horizontal reach of between 9.65 meters and 24.38 meters and working heights of 14.20 meters to 40.15 meters. Compared with various other aerial work platforms, telescoping booms have a a range of horizontal reach that is much greater. Genie telescopic booms are engineered with consideration to being able to access tight areas during construction and industrial applications. They are also known for their ability to quickly maneuver through a job site with great traction and drive speed. The platform hydraulically turns 160�° and could stay level through the whole range. Front-entry platforms come with 227 kilogram to 272 kilogram capacity for tools and operators and are available from 1.83 meters to 2.44 meters. Continuous, 360�° rotating turntables provide operators easy, quick positioning.
The Z-135/70 unit comes equipped with a Jib-Extend, that is a telescoping jib. It extends from 3.66 meters to 6.1 meters. This model can also reach 110�° vertically to give the user the ability to reach tasks that were inaccessible by conventional jibs before. A secondary reverse-articulating boom on the Z-80/60 model gives the user 8.83 meters of over and up reach. This specific feature allows over and up reaching jobs to be done with zero front arm swing.
Genie also provides the Fast Mast system that allows for precious time to be saved when both secondary and primary booms need to be lifted or for lowering the platform without having to lower the secondary boom. The Fast Mast system enables both booms to be fully raised at the same time. Both of these features of the Genie Fast Mast system lessens the time required for users to descend and ascend, increasing efficiency and productivity.
